• Quick jet flat fan quick dismantling nozzle requires a quick 1/4″ and 3/8″ turn of the wrist to remove spray tips. No tools are required.
• Choose with angles from 65° to 95°. Material is an engineering grade of polypropylene.
• Quick jet flat fan quick dismantling nozzle features a retainer cap. Simply unscrew the cap and remove the spray tip. Insert the new tip and tighten the retainer cap.
|
Quick Jet Flat Fan Quick Dismantling Nozzle |
Flat Fan Quick Dismantling Nozzle |
General Application
1) Industrial plating
2) Etching machine
3) Development
4) PCB washing or cleaning
5) Cooling
6) Metal finishing
7) Coating
Parameter
|
Flat Fan |
|||||||||||||
|
Style No. (spray angle at 3bar) |
Flow rate ( l / m ) |
||||||||||||
|
65° |
80° |
95° |
110° |
0.3bar |
1bar |
2bar |
3bar |
4bar |
5bar |
6bar |
7bar |
14bar |
|
| – | – | – | – |
0.12 |
0.23 |
0.32 |
0.39 |
0.46 |
0.51 |
0.56 |
0.60 |
0.85 |
|
|
QC6502 |
QC8002 |
– | – |
0.25 |
0.45 |
0.64 |
0.79 |
0.91 |
1.0 |
1.1 |
1.2 |
1.7 |
|
| – | – |
QC6903 |
– |
0.37 |
0.69 |
0.97 |
1.2 |
1.4 |
1.5 |
1.7 |
1.8 |
2.6 |
|
| – | – | – | – |
0.50 |
0.92 |
1.3 |
1.6 |
1.8 |
2.0 |
2.2 |
2.4 |
3.4 |
|
|
QC6505 |
QC8005 |
QC9505 |
– |
0.62 |
1.1 |
1.6 |
2.0 |
2.3 |
2.5 |
2.8 |
3.0 |
4.3 |
|
|
QC6506 |
QC8006 |
– | – |
0.75 |
1.3 |
1.9 |
2.4 |
2.7 |
3.1 |
3.3 |
3.6 |
5.1 |
|
|
QC6508 |
QC8008 |
QC9508 |
– |
1.0 |
1.8 |
2.6 |
3.2 |
3.6 |
4.1 |
4.5 |
4.8 |
6.8 |
|
|
QC6510 |
QC8010 |
QC9510 |
– |
1.2 |
2.3 |
3.2 |
3.9 |
4.6 |
5.1 |
5.6 |
6.0 |
8.5 |
|
|
QC6515 |
– | – | – |
1.9 |
3.4 |
4.8 |
5.9 |
6.8 |
7.6 |
8.4 |
9.0 |
12.8 |
|
| – |
QC8020 |
– | – |
2.5 |
4.6 |
6.5 |
7.9 |
9.1 |
10.2 |
11.2 |
12.1 |
17.1 |
|
|
QC6530 |
– | – | – |
3.7 |
6.8 |
9.7 |
11.8 |
13.7 |
15.3 |
16.7 |
18.1 |
26 |
|
|
Nozzle body No. |
Thread size |
|
|
QJJ 1/8” |
1/8” |
|
|
QJJ 1/4” |
1/4” |
|
|
QJJ 3/8” |
3/8” |
|
|
body |
QJJB 1/4” |
1/4” (Hollow cone) |
Ordering information
|
QJJ |
1/4” |
QC6502 |
PP |
|
↓ |
↓ |
↓ |
↓ |
|
Body No. |
Thread size |
Spray tip no. |
Material |
