• LNN AAZ Fine Atomizing Misting Nozzlesconsist of nozzle body, swirl core, spray header and filter, which produce fine mist.
• The swirl core is a component with slots on it by which the liquid flow rates and path are regulated.
• The slots of swirl core make the liquid spin in a circle at a very high speed. The energy from the spinning action causes the liquid to break up into very small droplets.
• Compared with impeller type nozzles and impingement nozzles, the swirl core type nozzles have wider applicability.
• This type of nozzles are widely used for snow making, gas cooling, light misting, humidifying, fogging, dust control, moistening, evaporative cooling, fire suppression, chemical processing.
|
LNN AAZ Fine Atomizing Misting Nozzles |
Fine Atomizing Misting Nozzles |
Description
|
Model |
AAZ-W； AAZ-N； AAZ-M |
|
Inlet connection |
1/4’’ |
|
Orifice dia. |
2.2mm/1.9mm/1.6mm/1.5mm/1.1mm/0.71mm/0.51mm/0.41mm |
|
Water pressure |
70bar/50bar/20bar/15bar/10bar/6bar/5bar/3bar/2bar |
|
Spray angle |
91/°90°/89°/88°/86°/85°/84°/82°/81°/79°/78°/77°/75°/74°/73°/72°/70°/65°/62°/45°/35° |
|
AAZ-W 1/4” female, with filter inside |
AAZ-N 1/4” male, with filter inside |
AAZ-M 1/4” male, with filter |
Parameter
|
Style NO. |
Orifice Dia. |
Core No. |
Flow rate(L/h) |
Spray angle |
||||||||||
|
AAZ-W |
AAZ-N |
AAZ-M |
||||||||||||
|
2bar |
5bar |
10bar |
15bar |
20bar |
50bar |
70bar |
3bar |
6bar |
20bar |
|||||
|
1/4AAZ W0.60 |
1/4AAZ N0.60 |
1/4AAZ M0.60 |
0.41 |
206 |
– |
– |
4.3 |
5.3 |
6.1 |
9.7 |
11.4 |
– |
35° |
65° |
|
1/4AAZ W1 |
1/4AAZ N1 |
1/4AAZ M1 |
0.51 |
210 |
– |
5.1 |
7.2 |
8.8 |
10.2 |
16.1 |
19.1 |
45° |
62° |
72° |
|
1/4AAZ W1.5 |
1/4AAZ N1.5 |
1/4AAZ M1.5 |
0.51 |
216 |
4.8 |
7.6 |
10.8 |
13.2 |
15.3 |
24 |
29 |
65° |
70° |
72° |
|
1/4AAZ W2 |
1/4AAZ N2 |
1/4AAZ M2 |
0.71 |
216 |
6.4 |
10.2 |
14.4 |
17.7 |
20 |
32 |
38 |
70° |
75° |
77° |
|
1/4AAZ W3 |
1/4AAZ-N3 |
11/4AAZ M3 |
0.71 |
220 |
9.7 |
15.3 |
22 |
26 |
31 |
48 |
57 |
65° |
70° |
73° |
|
1/4AAZ W4 |
1/4AAZ-N4 |
1/4AAZ M4 |
1.1 |
220 |
12.9 |
20 |
29 |
35 |
41 |
64 |
76 |
72° |
81° |
84° |
|
1/4AAZ W6 |
1/4AAZ N6 |
1/4AAZ M6 |
1.1 |
225 |
19.3 |
31 |
43 |
53 |
61 |
97 |
114 |
73° |
79° |
81° |
|
1/4AAZ W8 |
1/4AAZ N8 |
1/4AAZ M8 |
1.5 |
225 |
26 |
41 |
58 |
71 |
82 |
129 |
153 |
85° |
89° |
91° |
|
1/4AAZ W10 |
1/4AAZ N10 |
1/4AAZ M10 |
1.6 |
420 |
32 |
51 |
72 |
88 |
102 |
161 |
191 |
82° |
84° |
86° |
|
1/4AAZ W12 |
1/4AAZ N12 |
1/4AAZ M12 |
1.9 |
420 |
39 |
61 |
86 |
106 |
122 |
193 |
230 |
78° |
82° |
85° |
|
1/4AAZ W14 |
1/4AAZ N14 |
1/4AAZ M14 |
1.9 |
421 |
45 |
71 |
101 |
124 |
143 |
225 |
265 |
85° |
88° |
90° |
|
1/4AAZ W18 |
1/4AAZ N18 |
1/4AAZ M18 |
1.9 |
422 |
58 |
92 |
130 |
159 |
183 |
290 |
345 |
81° |
84° |
86° |
|
1/4AAZ W22 |
1/4AAZ N22 |
1/4AAZ M22 |
1.9 |
625 |
71 |
112 |
159 |
194 |
225 |
355 |
420 |
70° |
72° |
75° |
|
1/4AAZ N26 |
1/4AAZ N26 |
1/4AAZ M26 |
2.2 |
625 |
84 |
133 |
187 |
230 |
265 |
420 |
495 |
73° |
74° |
77° |
Ordering information
|
AAZ |
1/4’’ |
SS |
AAZ-M0.6 |
|
↓ |
↓ |
↓ |
↓ |
|
Nozzle Type |
Thread Size |
Material |
Flow code |
Application pictures
|
Dust control |
Dust suppression |
Hot Tags: LNN AAZ Fine Atomizing Misting Nozzles, China, manufacturers, suppliers, factory, price
