● Adjustable pressure-fed Flat Fan Air Atomizing Nozzles produce finely atomized spray, mist or fog
● Both Air and liquid working pressure is usually 2 -3 bar.
● Adjustable flow rate allows different choices of capacities
● Adjustable pressure-fed Flat Fan Air Atomizing Nozzles provide independent control of liquid, atomizing air and fan air pressure for fine tuning of flow rate, drop size, spray distribution and coverage.
General Application
1) Coating, cooling, humidifying
2) Gas cooling
3) Lubricating, moistening
4) Misting, fogging
5) Dust suppression
Description
|
Model |
JN |
|
Type |
Adjustable |
|
Spray pattern |
Flat Fan |
|
Working way |
Pressure |
|
Mix |
Internal |
Parameter
|
Spray set-up |
Liquid cap / Air cap No. |
Liquid capacity(L/h) & Air capacity(L/min) |
Spray distance |
||||||||||
|
1.5bar ( liquid) |
2bar ( liquid) |
3bar ( liquid) |
Air pressure (bar) |
Liquid pressure (bar) |
D（m) |
||||||||
|
Air pressure （bar) |
Water capacity |
Air capacity |
Air pressure （bar) |
Water capacity |
Air capacity |
Air pressure （bar) |
Water capacity |
Air capacity |
|||||
|
SU13A |
Liquid cap 2050 / |
1.3 |
9.1 |
31 |
2.0 |
8.6 |
42 |
2.7 |
11.2 |
52 |
1.1 |
0.7 |
2.6 |
|
1.5 |
7.7 |
36 |
2.2 |
7.5 |
47 |
3.0 |
10.1 |
56 |
2.1 |
1.5 |
3.0 |
||
|
1.8 |
6.5 |
42 |
2.5 |
6.2 |
52 |
3.2 |
9.1 |
62 |
2.8 |
2.0 |
3.2 |
||
|
2.1 |
5.4 |
47 |
2.8 |
5.2 |
57 |
3.5 |
8.1 |
66 |
3.5 |
3.0 |
3.4 |
||
|
2.4 |
4.3 |
52 |
3.1 |
4.2 |
63 |
4.2 |
5.4 |
79 |
6.0 |
4.0 |
4.0 |
||
|
2.7 |
3.3 |
57 |
3.2 |
3.7 |
65 |
4.6 |
4.2 |
85 |
– |
– |
– |
||
|
2.8 |
2.8 |
60 |
3.4 |
3.2 |
68 |
4.9 |
3.1 |
91 |
– |
– |
– |
||
|
SU13 |
Liquid cap 2850 / |
1.4 |
14.4 |
27 |
2.1 |
13.5 |
36 |
2.7 |
19.1 |
42 |
1.1 |
0.7 |
2.1 |
|
1.7 |
11.9 |
32 |
24 |
11.4 |
42 |
3.0 |
17.1 |
46 |
2.1 |
1.5 |
2.4 |
||
|
2.0 |
9.5 |
37 |
2.7 |
9.2 |
47 |
3.2 |
15.1 |
52 |
3.0 |
2.0 |
2.6 |
||
|
2.1 |
8.3 |
40 |
3.0 |
7.1 |
53 |
3.5 |
13.1 |
57 |
3.5 |
3.0 |
2.7 |
||
|
2.2 |
7.1 |
43 |
3.2 |
5.0 |
59 |
4.2 |
8.1 |
72 |
5.6 |
4.0 |
3.2 |
||
|
2.4 |
6.1 |
46 |
3.4 |
4.0 |
63 |
4.6 |
5.9 |
79 |
– |
– |
– |
||
|
2.5 |
5.1 |
49 |
3.5 |
3.3 |
66 |
4.9 |
4.0 |
86 |
– |
– |
– |
||
|
SUN13 |
Liquid cap 2850 / Air cap 7335 |
2.0 |
10.4 |
41 |
2.4 |
11.6 |
48 |
3.1 |
15.6 |
56 |
1.4 |
0.7 |
3.0 |
|
2.1 |
9.3 |
45 |
2.5 |
10.4 |
51 |
3.2 |
14.6 |
59 |
2.5 |
1.5 |
3.7 |
||
|
2.2 |
8.2 |
48 |
2.7 |
9.4 |
54 |
3.4 |
13.7 |
62 |
3.2 |
2.0 |
4.0 |
||
|
2.5 |
6.1 |
55 |
3.0 |
7.3 |
61 |
3.8 |
10.8 |
71 |
3.8 |
3.0 |
4.2 |
||
|
2.8 |
4.3 |
62 |
3.2 |
5.5 |
68 |
4.2 |
8.5 |
82 |
5.3 |
4.0 |
4.8 |
||
|
3.1 |
3.0 |
69 |
3.5 |
4.1 |
75 |
4.9 |
5.2 |
98 |
– |
– |
– |
||
|
3.4 |
2.0 |
75 |
3.8 |
2.9 |
81 |
6.0 |
2.3 |
120 |
– |
– |
– |
||
|
SU14 |
Liquid cap 2850 / |
2.1 |
7.4 |
40 |
3.0 |
6.1 |
52 |
3.9 |
9.4 |
60 |
1.5 |
0.7 |
1.8 |
|
2.4 |
5.3 |
45 |
3.1 |
5.3 |
54 |
4.2 |
7.2 |
67 |
2.7 |
1.5 |
2.0 |
||
|
2.5 |
4.4 |
47 |
3.2 |
4.5 |
57 |
4.6 |
5.3 |
73 |
3.2 |
2.0 |
2.0 |
||
|
2.7 |
3.7 |
50 |
3.4 |
3.8 |
59 |
4.9 |
3.8 |
80 |
4.2 |
3.0 |
2.1 |
||
|
2.8 |
3.1 |
52 |
3.5 |
3.2 |
62 |
– |
– |
– |
5.6 |
4.0 |
2.3 |
||
|
3.0 |
2.6 |
55 |
3.9 |
1.8 |
68 |
– |
– |
– |
– |
– |
– |
||
|
3.1 |
2.1 |
57 |
– |
– |
– |
– |
– |
– |
– |
– |
– |
||
|
SUN23 |
Liquid cap 60100 |
2.0 |
24 |
44 |
2.4 |
28 |
51 |
3.4 |
38 |
72 |
1.1 |
0.7 |
2.4 |
|
2.1 |
18.9 |
50 |
2.5 |
23 |
59 |
3.5 |
33 |
80 |
2.1 |
1.5 |
3.0 |
||
|
2.2 |
14.4 |
56 |
2.7 |
18.3 |
66 |
3.7 |
28 |
89 |
2.8 |
2.0 |
3.4 |
||
|
2.4 |
10.6 |
63 |
2.8 |
15.1 |
74 |
3.8 |
23 |
97 |
3.7 |
3.0 |
3.6 |
||
|
2.5 |
7.2 |
71 |
3.0 |
11.7 |
79 |
3.9 |
19.7 |
105 |
4.9 |
4.0 |
4.0 |
||
|
– |
– |
– |
– |
– |
– |
4.2 |
13.1 |
120 |
– |
– |
– |
||
|
– |
– |
– |
– |
– |
– |
4.6 |
7.2 |
138 |
– |
– |
– |
||
|
SUN23B |
Liquid cap 40400 / |
2.1 |
18.0 |
79 |
2.7 |
19.6 |
93 |
3.5 |
27 |
112 |
1.4 |
0.7 |
3.0 |
|
2.2 |
15.8 |
84 |
2.8 |
17.3 |
98 |
3.7 |
25 |
116 |
2.4 |
1.5 |
3.2 |
||
|
2.4 |
13.6 |
89 |
3.0 |
15.2 |
103 |
3.8 |
23 |
121 |
3.0 |
2.0 |
3.4 |
||
|
2.5 |
11.6 |
95 |
3.1 |
13.2 |
109 |
3.9 |
21 |
126 |
3.7 |
3.0 |
3.5 |
||
|
– |
– |
– |
3.2 |
11.4 |
114 |
4.1 |
18.9 |
132 |
5.3 |
4.0 |
4.0 |
||
|
– |
– |
– |
– |
– |
– |
4.2 |
17.0 |
137 |
– |
– |
– |
||
|
– |
– |
– |
– |
– |
– |
– |
– |
– |
– |
– |
– |
||
|
SU23 |
Liqudi cap 60100 |
1.8 |
38 |
55 |
2.4 |
39 |
67 |
3.2 |
58 |
76 |
1.1 |
0.7 |
3.4 |
|
2.1 |
28 |
66 |
2.7 |
30 |
77 |
3.5 |
47 |
87 |
2.4 |
1.5 |
3.5 |
||
|
2.2 |
24 |
71 |
3.0 |
24 |
87 |
3.8 |
38 |
97 |
3.2 |
2.0 |
3.7 |
||
|
2.4 |
21 |
76 |
3.2 |
17.8 |
98 |
3.9 |
34 |
103 |
3.9 |
3.0 |
3.8 |
||
|
2.5 |
17.8 |
82 |
3.4 |
15.1 |
103 |
4.2 |
27 |
113 |
6.0 |
4.0 |
4.4 |
||
|
2.7 |
15.1 |
87 |
3.5 |
12.9 |
109 |
4.6 |
20 |
126 |
– |
– |
– |
||
|
– |
– |
– |
3.7 |
10.6 |
114 |
4.9 |
14.8 |
140 |
– |
– |
– |
||
|
SU43 |
Liquid cap 100150 |
1.8 |
56 |
117 |
2.1 |
100 |
119 |
3.0 |
126 |
140 |
1.0 |
0.7 |
3.4 |
|
2.0 |
40 |
133 |
2.2 |
79 |
133 |
3.1 |
110 |
151 |
1.8 |
1.5 |
3.8 |
||
|
– |
– |
– |
2.4 |
62 |
147 |
3.2 |
95 |
163 |
2.4 |
2.0 |
4.3 |
||
|
– |
– |
– |
2.5 |
48 |
162 |
3.4 |
78 |
184 |
3.4 |
3.0 |
4.6 |
||
|
– |
– |
– |
2.7 |
36 |
177 |
3.5 |
62 |
193 |
4.9 |
4.0 |
5.2 |
||
|
– |
– |
– |
– |
– |
– |
3.7 |
48 |
210 |
– |
– |
– |
||
|
– |
– |
– |
– |
– |
– |
3.8 |
37 |
225 |
– |
– |
– |
||
Ordering information
|
JN |
1/4’’ |
SS |
SU13A |
SS |
|
↓ |
↓ |
↓ |
↓ |
↓ |
|
Nozzle Type |
Thread Size |
Air cap material code |
Spraying devoice No. |
Liquid cap material code |
Application pictures
Dust control
Hot Tags: adjustable pressure-fed flat fan air atomizing nozzles, China, manufacturers, suppliers, factory, price
