Features
Features
• The atomization of Adjustable Cannon Fog Misting Nozzles give a filmy feeling.
• The flow rate and spray angle of the Adjustable Fog Cannon Misting Nozzlescan be adjusted.
• The spray distance can reach 30 to 100 meters when connected with air blower.
• The coverage area can be adjusted in a small range. When the nozzle reaches the atomization, the water is very fine, and the atomization effect is very good.
• The water pressure requirements are relatively low, even tap water pressure can be sprayed.
• Easy to install, good water-saving performance.
|
Adjustable Fog Cannon Misting Nozzles |
Fog Cannon Misting Nozzles |
Description
|
Model |
WPF（female）； WPM（male） |
|
Inlet connection |
1/4’’ |
|
Orifice dia. |
1.5mm/1.2mm/1.1mm/1mm |
|
Water pressure |
35bar/20bar/10bar/7bar/6bar/5bar/4bar/3bar/2bar |
Parameter
|
Orifice dia. |
Flow rate(L/min) |
||||||||
|
2bar |
3bar |
4bar |
5bar |
6bar |
7bar |
10bar |
20bar |
35bar |
|
|
1 |
0.22 |
0.26 |
0.31 |
0.34 |
0.37 |
0.40 |
0.48 |
0.68 |
0.90 |
|
1.1 |
0.29 |
0.33 |
0.37 |
0.41 |
0.43 |
0.47 |
0.53 |
0.7 |
0.95 |
|
1.2 |
0.32 |
0.39 |
0.46 |
0.51 |
0.56 |
0.6 |
0.72 |
1.0 |
1.3 |
|
1.5 |
0.39 |
0.48 |
0.55 |
0.61 |
0.67 |
0.72 |
0.86 |
1.3 |
1.7 |
Ordering information
|
WP |
1/4’’ |
SS |
1 |
|
↓ |
↓ |
↓ |
↓ |
|
Nozzle Type |
Thread Size |
Material |
Orifice dia. |
Application pictures
|
Dust control |
Fog cannon machine nozzles |
